Pergola post spacing: three measurements that get the layout right

Pergola post spacing comes down to the beam span your timber can carry without sagging, and most designs settle somewhere between two and three metres between posts. Go wider than your beam allows and you'll see deflection over time, especially once climbing plants or a roof covering add weight. This guide at Blakesleys walks through how span, timber size and ground conditions decide your layout, so you can plan posts that hold their line for years.

Beam span and what decides it

The span is the distance a beam has to cross unsupported between two posts. The wider the span, the deeper or thicker the beam needs to be to resist bending under its own weight and whatever sits on top of it. This is why spacing isn't really a fixed number: it's a relationship between the timber you're using and the load you're asking it to carry.

A slim beam over a long span will sag visibly within a season, even if it looks fine on the day you build it. Oversizing the beam a little costs you very little in materials and buys a lot of peace of mind. If you haven't settled on your timber yet, it's worth reading about how post and beam dimensions are chosen together before fixing your spacing.

Softwood versus hardwood spans

Softwood beams, the kind most DIY pergolas use, generally need tighter spacing than hardwood for the same visual thickness. Hardwood carries further before it needs intermediate support, but it costs more and is harder to work with hand tools. Neither is wrong; it's a trade-off between budget, tools and how far you want posts set apart.

Working out your layout

Start from the footprint you want, then divide it into bays that match what your beam size can span safely. A rectangular pergola over a patio, for example, might split into three equal bays rather than one long uninterrupted run. Shorter bays mean more posts, but each beam works less hard and the whole structure feels more rigid underfoot and overhead.

• Measure the full length and width you want covered
• Divide the longer side into bays no wider than your beam's safe span
• Check the shorter side against the same rule for cross beams
• Adjust bay width slightly so posts land clear of paths, drains or steps

Freestanding versus attached layouts

A freestanding pergola carries its own weight on posts at every corner and along every side, so spacing is symmetrical and you have full control over where posts fall. An attached structure, fixed to the house at one side with a ledger board, only needs posts along the open edges, which changes how the spans balance out. If you're still deciding which structure suits your garden, it's worth comparing how a pergola and a veranda differ in shelter and build before locking in a layout.

Corner posts and mid-span posts

Corner posts carry load from two directions at once, so they're never optional. Mid-span posts, set along a long run, exist purely to shorten the beam's span and stop it sagging. Skipping a mid-span post to save on a hole and some concrete is the single most common shortcut that leads to a drooping roofline later.

Load that changes the maths

Bare rafters carry far less than a pergola roofed in solid panels, so your spacing needs headroom for whatever you plan to add later. Wisteria and other heavy climbers add real weight once established, and wind pushes against any roof covering far harder than it pushes against open slats. If a roof is part of your plan, the structural checks in adding a roof to an existing pergola are worth reading alongside your spacing decisions.

Wind load matters more than most people expect. A solid or louvred roof acts like a sail, and posts spaced for an open frame may not be enough once that covering goes on. Tightening your spacing at the planning stage is far easier than adding a post after the structure is built.

Ground conditions and post spacing

Soft or sloped ground can force tighter spacing even when your timber could technically span further, because each post needs a stable footing to resist leaning. On firm, level ground, you have more freedom to stretch bays toward the limit your beam allows. Where the ground is uneven or drains poorly, shorter spans spread the load across more footings and reduce the strain on any one point.

The foundations under each post matter just as much as the spacing above them. Depth, footing type and how the soil behaves all feed into how far apart posts can safely sit, which is covered in detail in what foundations a pergola actually needs.

A simple way to compare layouts

Checking your plan before you dig

1. Confirm your beam size against the span you want each bay to cover
2. Mark out post positions on the ground with pegs and string
3. Check every corner and mid-span point lands clear of obstructions
4. Walk the layout and picture the roof covering you intend to add
5. Adjust spacing before you order concrete or dig a single footing

Starting your layout this week

You don't need the full design finished to make progress; a rough sketch and a tape measure will get you most of the way there.

• Measure your footprint and sketch two or three bay options on paper
• Peg out your preferred layout on the actual site
• Note where the ground feels soft, sloped or uneven underfoot
• Decide now whether a roof covering is part of the plan, before you fix spacing

#Posts #Beams #Span

Download PDF: Pergola post spacing checklist PDF, 28 KB
